Fabric duct mounting options

Textile diffuser systems are often installed using aluminum track that can be either surface mounted to the ceiling or suspended using cable or threaded rod hangers.

Systems can also be installed using high-tension cable to which the diffuser is hung with clips or hooks.

Single, double, or triple track, or cable systems may be required depending on the diffuser size.

Home Engineers 1

These are the most common mounting styles for both suspension and surface-mount installations. For more detailed information, see our Installation Videos and download our Technical Data Full Catalog.

MountingStyles 1 instalace 1 3 1024x690 1 e1591730707243

SINGLE CABLE

Simple single-wire suspension.

MountingStyles 2 instalace 1 3 1024x690 1 e1591730674244

DOUBLE CABLE

Two-wire suspension installation.

MountingStyles 5 instalace 1 3 1024x690 1 e1591730574555

SUSPENSION MOUNTED SINGLE TRACK

Single profile (track).

MountingStyles 3 instalace 1 3 1024x690 1 e1591730638419

SURFACE MOUNTED SINGLE TRACK

Single profile (track).

MountingStyles 4 instalace 1 3 1024x690 1 e1591730598841

SURFACE MOUNTED DOUBLE TRACK

Two-wire surface installation.

MountingStyles 7 instalace 1 3 1024x690 1 e1591730481199

END CAP MOUNTING

MountingStyles 6 instalace 1 3 1024x690 1 e1591730518682 600x388 1

SUSPENSION MOUNTED DOUBLE TRACK

MountingStyles half round

SURFACE MOUNTED HALF ROUND

MountingStyles 9 instalace 1 3 1024x690 1 e1591730403379

SUSPENSION MOUNTED HALF ROUND

MountingStyles quarter round

SURFACE MOUNTED QUARTER ROUND

MountingStyles 11 instalace 1 3 1024x690 1 e1591730329562

SUSPENSION MOUNTED RECTANGULAR

MountingStyles 10 instalace 1 3 1024x690 1 e1591730373262

SURFACE MOUNTED RECTANGULAR
